d2 GRP Phenolic — fire-rated grating for tunnels and offshore
Developed to withstand prolonged fire exposure without losing structural function. Dura Phenolic is a phenolic resin-based GRP grating with very high fire resistance and low smoke and toxicity emissions. It is used, amongst other applications, on offshore platforms, mobile drilling rigs, tunnels and underground railway systems. The product is tested to BS 6853 and BS 476 Class 0 and approved for use on the London Underground. Fire rating and approvals must be verified against the current technical datasheet and project requirements.
d2 GRP Phenolic is a high-strength GRP grating developed for environments with especially high fire safety requirements. The material has very good resistance to open flame and high temperatures and is engineered to retain its load-bearing capacity even under prolonged fire exposure.
The GRP grating emits less smoke and lower levels of toxic combustion gases than many other types of GRP grating. This makes it particularly suitable for tunnels, basement areas, public transport systems, offshore platforms and drilling installations. Its high structural performance also makes it a safe choice for elevated platforms and other structures where safety is critical.
d2 GRP Phenolic also combines high strength with low weight, an anti-slip surface and electrically insulating properties. It is a durable, low-maintenance alternative to traditional metal grating in demanding, fire-exposed environments.
Price on request — contact us for a quote and stock availability.
Request a quoteIdeal for tunnels, basements and offshore
Fire-rated performance
Engineered to withstand prolonged fire exposure with low smoke and toxicity emissions.
Anti-slip surface
Only 5% degradation after 1 million footsteps (BS 7976).
High strength
Superior structural performance with an exceptional strength-to-weight ratio.
Non-conductive
Ideal for reducing risk in high-voltage areas and hazardous environments.
Phenolic — technical data
Also known as: GRP Phenolic grating · phenolic resin grating · Dark Russet grating
- 38 mm
- Dark Russet
- 38 mm
- 3660 mm
- 38 mm
- 1220 mm
- 38 mm
- 85,10 kg
- 38 mm
- 19,06 kg
- 38 mm
- BS 6853, BS 476 Klass 0
- 38 mm
- Endast 5 % försämring efter 1 miljon fotsteg
| Property | 38 mm |
|---|---|
| Colour | Dark Russet |
| Length | 3660 mm |
| Width | 1220 mm |
| Weight per panel | 85,10 kg |
| Weight per m² | 19,06 kg |
| Fire rating | BS 6853, BS 476 Klass 0 |
| Slip resistance | Endast 5 % försämring efter 1 miljon fotsteg |
Need further technical information, point load or UDL data? Contact us for full documentation.
Click to see details
d2 Dura Phenolic — item numbers
| Product | Type | Item no. |
|---|---|---|
| d² Dura Phenolic 38 mm | Panel | On request |
| Dome Washer | Large | Fixing | BFX01003 |
| Dome Washer | Extra Large | Fixing | BFX02165 |
| M Clip | Standard Shallow | Fixing | BFX01011 |
| M Clip | Standard Deep | Fixing | BFX01013 |
| M Clip | Standard Extra Deep | Fixing | BFX01014 |
| J Clamp | Offset | Fixing | FX01128 |
| Uni-Strut Clamp | Fixing | DP05053 |
| Channel Clamp | Fixing | BFX01027 |
| Jaw Clamp | Fixing | FX01033 |
| G Clamp | Fixing | BFX01022 |
Item numbers for fixings according to the current d2 Dura Grating price list. Panel item numbers are assigned by height, mesh size and colour — contact us for code, price and stock availability.
Need technical advice?
Expert support for GRP solutions.
Detailed planning and CAD.
We come to your facility.
Certified installers on site.
Fast and accurate cost estimates.
More about d² Dura Grating Phenolic
Byggkomposit is the exclusive Swedish distributor for Dura Composites. Technical data sheets, load tables and certificates are published on the manufacturer's own product page.
